• Direct replacement for OEM AUC13965 on for John Deere 47 inch and 54 inch front mount snow blowers and installs using the factory bolt pattern

• CNC machined from solid 6061 T6 billet aluminum with side walls approximately 0.80 inch thick, eliminating the bending and corner damage common with the thin stamped steel factory cover

• Black Type 3 hardcoat anodize provides exceptional wear resistance and protection from corrosion, salt, and winter environments

• Includes two threaded service plugs. The center plug is used for filling and oil level checks, and the lower plug provides fast, clean draining during seasonal oil changes

• Precision machined O-ring groove provides a clean and reliable seal with no RTV or gasket maker required, eliminating the need to scrape off old sealant

• Compact profile sits inside the outer edges of the gearbox so the cover is not exposed like the stock stamped steel version and is far less likely to be struck by debris

• Patent pending design engineered by Push Industries, a USA based and owned company built by equipment enthusiasts who design, test, and use the same products they sell and take pride in reliable support after the sale

The Push Industries 118.688 Upgraded Billet Gearbox Cover is engineered as a heavy duty replacement for the OEM AUC13965 stamped steel cover used on 47 inch and 54 inch front mount snow blowers for John Deere. The original cover is a thin piece of stamped steel with corners that extend beyond the gear case. When the snowblower encounters ice, packed snow, or debris, those exposed corners are easily struck and can bend inward. Once bent, the OEM cover can distort the sealing surface or begin to seep at the gasket area.

This billet aluminum replacement eliminates those weaknesses. Each cover is CNC machined from solid 6061 T6 billet aluminum with side walls approximately 0.80 inch thick. While the OEM cover can bend from a debris strike, the billet version would require bending nearly an inch of solid aluminum, which simply will not happen under normal use. The Push Industries cover also features a compact footprint that does not protrude past the gearbox housing, greatly reducing exposure to impact.

To improve maintenance, the design incorporates two threaded service plugs. The center plug is used for oil filling and level checks, while a second plug at the bottom of the cover makes seasonal oil changes simple, clean, and fast. This feature eliminates the mess and hassle of draining through the gearbox opening or removing the entire cover.

A precision machined O-ring groove provides a repeatable, clean seal every time. There is no RTV or gasket maker required, and no need to scrape old sealant during service. The part is finished in black Type 3 hardcoat anodize for excellent surface hardness, abrasion resistance, and corrosion protection in harsh winter and salt conditions.

Installation is straightforward. The 118.688 cover uses the existing bolt pattern and hardware on for John Deere 47 inch and 54 inch blowers. Remove the OEM stamped steel cover, clean the surface, install the O-ring, and secure the billet cover in place.

This is a patent pending Push Industries design. Push Industries is a USA based and owned company built by tractor and equipment enthusiasts who design, test, and use the same products they manufacture. The 118.688 billet gearbox cover delivers long service life, improved sealing, easier maintenance, and significantly greater durability compared to the factory AUC13965 cover.
